Description

Description

Professional LED recessed lamp with IP68 protection, resistant to water pressure and a maximum immersion depth of 10 meters. Insulation class III. Stainless steel appliance n. ref. 1.4401, electropolished with clear safety glass and silicone seal. Reflector in pure anodized aluminium. Cable resistant to chlorine water. Recommended recess depth 400 – 700 mm from the water surface. For the use of the devices, a power supply is required, which you can find in our shop. Cable length 3 meters. To avoid impurities and harmful deposits on the appliances, the water must have a neutral pH and must be free from components that are corrosive to the metal. The national safety regulations must be observed for the installation and use of these devices. 20-year guarantee on the LED module. Dimensions: 195mm (diameter) x 65mm (depth) x 150mm (hole).

Features:

• Module power: 8,4 W
• Appliance power: 9.9 W
• Reference temperature: ta = 25 ° C
• Ambient temperature: max = 65 ° C
• Model: 99- 812 -K3
• Module name: LED-0399/830
• color temperature: 3000 K
• Color rendering index: CRI> 80
• Luminous flux of the module: 1160 lm
• Luminous flux of luminaires: 815 lm
• Luminous efficiency of luminaires: 82.3 lm / Watt

Manufacturer : BEGA cancel Availability on order Availability on order

Data sheet :

Barcode

4044017240895

Reference

99812K3

Input voltage

24 VOLT DC

Depth in mm

65

Diameter in mm

195

Degree of protection

IP68

Material

Stanless steel

Light source

LED

Glass

Transparent

Watt power

9.9W

Light Temperature

3000 K Warm white

Product Color

STEEL COLOR

Beam angle

45°

Mounting diameter in mm

150

Driver power supply

Without driver

Insulation class

Insulation class III

Compatible voltage

EU-AUD-USA-UK-JAP

Color rendering index

CRI Greater than 80

Warranty : 2-year warranty from date of purchase counter_2 workspace_premium
